G17F, 4G communicator for fire control panels with antenna, White, TRIKDIS

The TRIKDIS G17F 4G communicator with antenna is designed to transmit fire alarm control panel events via mobile network to a monitoring station, TRIKDIS receivers, or directly to users through the Protegus app, SMS, or phone call.

• Communication and event reporting:
  • 4G LTE mobile communication with 2G backup channel
  • Event transmission to TRIKDIS software and hardware receivers
  • Supports SIA DC-09 and TRIKDIS communication protocols
  • Connection supervision with periodic test reports
  • User notifications via Protegus app, SMS messages, or phone calls
• Inputs and interfaces:
  • 6 programmable inputs for monitoring fire control panel statuses
  • Input types: NC, NO, or EOL with 10 k? resistor
  • 3 dedicated inputs and 3 universal I/O terminals
  • RS485 / Serial interface for connection to supported fire alarm control panels
  • Input expansion available with iO series expanders
• Configuration and control:
  • Configuration via TrikdisConfig software
  • Remote configuration and firmware updates supported
  • Output control via Protegus app, SMS, or phone call
• Power and package:
  • Power supply: 12–24 V DC
  • Standby current approx. 50 mA, up to 200 mA during transmission
  • Supplied with 4G antenna
  • Uses a Nano SIM card
• Certification and application:
  • Designed for fire alarm control panels
  • Complies with EN 54-21 requirements
  • Ensures priority transmission of fire alarm events
