VSC HD5VDAE2F28 5MP HD Camera, AHD / TVI / CVI / CVBS, 2.8mm, IR30

The VSC HD5VDAE2F28 is a 5 MP dome-style HD camera designed for high-resolution analog CCTV systems. It features a fixed 2.8 mm wide-angle lens, enhanced AE2 low-light imaging and IR night vision up to 30 m. With 4-in-1 output (AHD / TVI / CVI / CVBS), the camera is compatible with all modern coaxial DVR platforms.

Main features:

• Resolution: 5 MP (approx. 2592 × 1944) for sharp, detailed video quality.
• Lens: Fixed 2.8 mm wide-angle lens, ideal for rooms, entrances, hallways, shops and office spaces.
• Enhanced sensor: AE2 low-light sensor ensures improved nighttime clarity and reduced noise.
• Video format: 4-in-1 output — AHD / HD-TVI / HD-CVI / CVBS (selectable via switch).
• Night vision: IR illumination up to 30 m for consistent performance in low-light environments.
• Housing: Dome-type enclosure suitable for indoor or sheltered outdoor mounting.
• Installation: Plug-and-play over coaxial cable; adjustable 3-axis bracket for flexible positioning.
• Compatibility: Works with all 4-in-1 and 5-in-1 HD DVRs.

Notes:

• 5 MP resolution offers significantly more detail than standard 2 MP or 4 MP analog cameras.
• The wide 2.8 mm lens provides broad scene coverage with minimal distortion.
• AE2 sensor technology enhances low-light performance and improves contrast in darker areas.
